Established in 1967 as a wire job shop, WireCrafters LLC has grown to become the nation’s leading producer of wire partition products. We started by concentrating our efforts on one product and developed a partition system that has since changed the industry.
The inherent simplicity and strength of our Style 840 Wire Partition System opened the door to many new applications for wire partitions. Not only can our system handle the traditional partition uses such as the construction of tool cribs, secured storage areas, and maintenance cages; customers also began using it for machine guards, physical barriers for robotic work cells, pallet rack backing, vertical lift enclosures, and DEA approved pharmaceutical enclosures.
RapidGuard® II Panels & Posts
Panels are made of 10 gauge welded wire and patterned in a 1 1/4″ SQ (center to center). The mesh is then welded into a 1 1/4″ x 1 1/4″ 13 gauge roll formed angle. Strong 2″ x 2″ 14 gauge tube posts have threaded inserts pre-drilled into the posts for quick mounting of the panels. Lift-Off Panels lift off from the upright posts, allowing easy access to the equipment you are guarding. RapidGuard® II is compliant with OSHA and ANSI/RIA safety standards. A variety of safety switches or interlocks can be supplied with a RapidGuard™ II door. System installs 50% faster than conventional physical barrier products.
- Standard size panels are 6′-1 1/2″H & 8′ high by 1′ to 5′ wide
- Panels install vertically between 6’6-3/4″H & 8′-5 1/4″H Posts (5 1/4″ sweep).
- Fully framed panel adds strength and stability unequaled in the industry.
- Hinged and slide doors available.
- Unique lift-off design allows for the removal of guards (panels) while the fixing system (hardware) remains attached to the guards (post), in compliance with RIA TR R15.406
5/16″-18 x 3/4″ tool removable hardware is compliant with ANSI B11.19 and RIA TR R15.406. - All hardware including anchors included.
- Stock powder coat black panels & yellow posts.
- An integrated lock out plat and pull handle are standard on hinge doors.
- Safety interlocks available with mounting plates.
- 13 GA 1-1/4″ x 1-1/4″ roll formed angle
- 2″ SQ 14GA posts with 6″ SQ x 1/4″ baseplates
Machine Guarding Systems
WireCrafters® Machine Guarding Systems offer a straightforward yet effective solution for protecting personnel from automated equipment hazards. These barriers are both strong and economical, easily integrating access doors or larger openings with system controls. Made from durable welded and woven wire mesh, they resist damage and require minimal maintenance. Bolted securely to posts, they provide a reliable barrier around hazardous machinery, offering constant protection without the risk of electrical malfunctions associated with other technologies.
- OSHA & ANSI/RIA R15.06-2014 Compliant
- Standard height of 5′-3 1/4″ with 0′-3 1/4″ sweep & 8′-5 1/4″ with 0′-3 1/4″ sweep.
- Custom size panels and special heights available.
- Fully framed panel adds strength and stability unequaled in the industry.
- Hinged, double hinged, sliding and vertical rise doors available.
- Angle frame design gives installer clear access to hardware, speeding installation.
- Assembly hardware is inaccessible from the secured side of the guarding.
- All hardware including anchors included.
- Standard 3/8″ mounting hardware is the heaviest in the industry.
- Panels may be ordered in alternate woven and welded mesh options, expanded metal, sheet metal, or clear polycarbonate.
- Safety Interlocks available with mounting plates.
